All ProductsTurck

Turck RM-28TA1R-3C24B-H1181/N16

SKU: CS5979165MPN: RM-28TA1R-3C24B-H1181/N16Alternate Part #: 200005120
Turck RI-01Q5F3-2A60-CA, RI-04Q6C-2H1000-H1181, RI-04Q6C-2H1000-H1481, RI-04Q6C-2H500-H1481, RI-04QA0C-2H500-C, RI-04QA0C-2H500-CA, RI-04T6S-1H200-C, RI-10S10C-2B50-H1181, RI-10S10C-2K2500-H1181, RI-10S10C-4A2500-H1481, RI-10S10C-4B4096-10MIL/N24/N40, RI-10S10C-CA1000-H1181, RI-10S10S-2B50-12M23, RI-10S10S0-2B1000-10MIL, RI-10S12C-4A1024-12M23
$1,629.32
Unit
Available on backorder
remove
add

Product Details

Absolute Shaft Encoder

Industrial Line

  • Absolute Shaft Encoder
  • Protection class IP65 on shaft side
  • -40…+85 °C
  • Max. 12000 rpm (continuous operation 10000)
  • 10…30 VDC
  • SSI, gray
  • M12 connector, 8-pin
  • Singleturn, 12-bit resolution
  • Multiturn, 12-bit resolution

Attributes

Ambient Temperature -40…+85 °C
Communication Protocol SSi
Ecl Ss Code V5 1 4 27270501 -/- Encoder, absolute
Electrical Connection Connector, M12 × 1
Encoder Line Industrial-Line
Flange Diameter Ø  63.5 mm
Flange Type Synchro flange
Housing Material Die-cast zinc
Operating Voltage 10…30 VDC
Output Type Absolute multiturn
Protection Class Housing IP67
Protection Class Shaft IP65
Shaft Diameter D Mm 9.525 mm
Shaft Type Solid shaft
Technology Optical

Specifications

SKUCS5979165
MPNRM-28TA1R-3C24B-H1181/N16
Alternate Part #200005120
