Turck NI3-EG08-AN7X
SKU: CS3814122MPN: NI3-EG08-AN7XAlternate Part #: 4669759
4669759 - FERRITE, BARREL, DC, CABLE
Contact us for pricing and availability
Product Details
Inductive Sensor
- M8 × 1 threaded barrel
- Stainless steel, 1.4404
- DC 3-wire, 10…30 VDC
- NO contact, NPN output
- TTL compatible
- Cable connection
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M8 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable |
| Housing Material | Stainless steel, 1.4427 SO |
| Mounting | Non-flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, NPN |
| Protection Class | IP67 |
| Rated Switching Distance | 3 mm |
| Switching Frequency | 3.0 kHz |
Specifications
| SKU | CS3814122 |
|---|---|
| MPN | NI3-EG08-AN7X |
| Alternate Part # | 4669759 |
