Turck NI2-K09-0.095/0.11-BDS-2AP6X3-H1141 / S34

Name: Turck NI2-K09-0.095/0.11-BDS-2AP6X3-H1141 / S34
Brand: Turck
SKU: CS3813984
Availability: OutOfStock

SKU: CS3813984MPN: NI2-K09-0.095/0.11-BDS-2AP6X3-H1141 / S34Alternate Part #s: 1650039TUR-NI2-K09-0.095/0.11-BDS-2AP6X3-H1141/S34UPC/EAN: 4047101081695

1650039 - FERRITE, CLAMP, DC, CON. M12

Turck NI2-K09-0.095/0.11-BDS-2AP6X3-H1141 / S34

Product Details

Inductive Sensor

Monitoring Kit for Power Clamps

BDS power block with two connected sensors and LEDs
Robust rotatable connector 0°, 45° and 90°, for optimal cable routing
Plastic, Trogamid

Resistant to magnetic fields (weld-resistant), for DC and AC fields up to 100 mT

2 x NO contact, PNP output
DC 4-wire, 10…30 VDC

Attributes

Ambient Temperature	-25…+70 °C
Customs Tariff Number	85365019900.0000
Design	Monitoring kit for power clamps
Ecl Ss Code V5 1 4	27270101 -/- Inductive proximity switch
Electrical Connection	Connector, M12 × 1
Housing Material	Metal, Trogamit
Mounting	Non-flush
Operating Voltage	10…30 VDC
Output Function	NO contact, PNP
Protection Class	IP67
Rated Switching Distance	1.2 mm
Special Feature	Resistant to magnetic fields
Switching Frequency	0.030 kHz
