Schneider Electric EPG107-AM

SKU: CS3640458MPN: EPG107-AMAlternate Part #: SENA-EPG107-AM

Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa

Schneider Electric, Veris EPG103-AM, EPG103-AV, EPG105-AM, EPG105-AV, EPG106-AM, EPG107-AV, EPG108-AM
$275.38
Unit
1 Unit Available at Factory - Ships Same/Next Business Day
remove
add

Product Details

Gauge Pressure Sensor

  • 2-wire* Input Power: 10-28 VDC* Output: 4-20mA* Pressure Range: 0-100 psig

Attributes

Us Rated Supply Voltage 10…28 V DC
Us Rated Supply Voltage 1 10…28 V DC
Ambient Air Temperature For Operation -30-120 °C
Ambient Air Temperature For Operation 1 -30-120 °C
Ambient Air Temperature For Operation 2 -30-120 °C
Analogue Output Type 4…20 mA
Burst Pressure 500 psig (34 bar)
Calibration Certificate none
Controlled Fluid water
Device Application pump and compressor monitoring# #gas pressure# #energy and water management# #refrigerant equipment monitoring
Fitting Size ¼” NPT
Fitting Type male
Ip Degree Of Protection IP66
Ip Degree Of Protection 1 IP66
Ip Degree Of Protection 2 IP66
Location plant room
Mounting Support pipe
Pressure Measurement Accuracy ± 0.25 % BFSL
Pressure Measurement Range 0…100 psi (0…7 bar)
Product Certifications CE
Product Certifications 1 CE
Product Or Component Type sensor
Range Of Product EPG
Relative Humidity 0-95 % RH, non-condensing
Relative Humidity 1 0-95 % RH, non-condensing
Targeted Region North America.
Type Of Measurement gauge pressure
Wiring Technique 3-wire# #2-wire (loop powered)

Specifications

SKUCS3640458
MPNEPG107-AM
Alternate Part #SENA-EPG107-AM
