Schneider Electric EPW105-LCD

Name: Schneider Electric EPW105-LCD
Brand: Schneider Electric
SKU: CS3108828
Price: 453.21 USD
Availability: InStock

SKU: CS3108828MPN: EPW105-LCDAlternate Part #: SENA-EPW105-LCD

Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa

$453.21

Unit

3 Units Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

Gauge Pressure Sensor

Wet Media* 3-wire* Input Power: 12 to 30VDC, 24VAC nom.* Field Selectable Outputs* 2% Accuracy at 25 C* LED Status Indicator* Pressure Range: 250 PSIG* LCD Display

Us Rated Supply Voltage	15…30 V DC 24 V AC
Us Rated Supply Voltage 1	15…30 V DC 24 V AC
Ambient Air Temperature For Operation	-10-50 °C
Ambient Air Temperature For Operation 1	-10-50 °C
Ambient Air Temperature For Operation 2	-10-50 °C
Analogue Output Type	4…20 mA# #0…5 V DC# #0…10 V DC
Burst Pressure	1250 psig (85 bar)
Calibration Certificate	none
Controlled Fluid	water
Device Application	pump and compressor differential pressure# #chiller differential pressure monitoring
Display Size	17 x 36 mm
Fitting Size	⅛” NPT
Fitting Type	female
Ip Degree Of Protection	IP65
Ip Degree Of Protection 1	IP65
Ip Degree Of Protection 2	IP65
Local Signalling	red/green LED
Location	plant room
Max Current Draw	125 mA DC 280 mA AC
Mounting Support	panel
Pressure Measurement Accuracy	range A/B: ± 1 % FS, range C: ± 1.5 % FS, range D: ± 2 % FS
Pressure Measurement Range	0…25 psi (0…1.7 bar)# #0…50 psi (0…3.5 bar)# #0…100 psi (0…7 bar)# #0…250 psi (0…17 bar)
Product Certifications	CE
Product Certifications 1	CE
Product Or Component Type	sensor
Range Of Product	EPW
Relative Humidity	0-90 % RH, non-condensing
Relative Humidity 1	0-90 % RH, non-condensing
Standards	EN 61000-6-1
Standards 1	EN 61000-6-1
Standards 2	EN 61000-6-1
Targeted Region	North America.
Type Of Measurement	differential pressure
Wiring Technique	3-wire
