Veris EPW2104

Name: Veris EPW2104
Brand: Veris
SKU: CS4178615
Price: 483.12 USD
Availability: InStock

SKU: CS4178615MPN: EPW2104

Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa

$483.12

Unit

2 Units Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

Gauge Pressure Sensor

Wet Media* 2-wire* Input Power: 12 to 30VDC, 24VAC nom.* Output: 4-20mA* 2% Accuracy at 25 C* LED Status Indicator* Pressure Range: 100 PSIG

IP Degree of Protection	IP65
Product or Component Type	sensor
Ambient Air Temperature for Operation	-10-55 °C
Burst Pressure	500 psig (34 bar)
Product Certifications	CE
Controlled Fluid	water
Fitting Size	⅛” NPT
Fitting Type	female
Location	plant room
Mounting Mode	wall mount
Pressure Measurement Accuracy	range A/B/C: ± 1 % FS, range D: ± 2 % FS
Type of Measurement	differential pressure
Device Application	pump and compressor differential pressure; chiller differential pressure monitoring
Mounting Support	panel
Output Type	analog 2-wire (loop powered) 4…20 mA polarity insensitive (clipped and capped)
Relative Humidity	10-90 % non-condensing
Device Short Name	EPW2
Enclosure Material	powder coated aluminium
Product Specific Application	select psi or bar by positioning jumper; to measure wet differential pressure
Environmental Characteristic	EMC
Current Consumption	20 mA
Fitting Material	stainless steel
Accuracy	± 2 % 25 °C
Adjustment	push-button auto-zero digital input (2-position terminal block)
Maximum Pressure	100 psig switch selectable
Max Current Draw	29 mA
