APC BE600M1

Name: APC BE600M1
Brand: APC
SKU: CS3156774
Availability: OutOfStock

SKU: CS3156774MPN: BE600M1Alternate Part #: APC-BE600M1UPC/EAN: 731304325116

APC Back-UPS 600VA, 120V, 1 USB charging port, 7 NEMA outlets (2 surge)

Documents

APC Manual

Product Details

APC Back-UPS BE600M1, 600VA, 120V,1 USB charging port

Battery Backup \& Surge Protector for Electronics and ComputersIncludes: User manual

Attributes

Sena Acoustic Level	35 dBA
Sena Alarm	alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Sena Ambient Air Temperature For Operation	0-40 °C
Sena Ambient Air Temperature For Storage	-15-45 °C
Sena Battery Charger Power	7 W rated
Sena Battery Curve	C
Sena Battery Life	3-5 year(s)
Sena Battery Recharge Time	10 h
Sena Battery Type	lead-acid battery
Sena Control Panel	LED status display with on line : on battery : replace battery and overload indicators
Sena Curve Equation	efficiency
Sena Curve Fixed Loss	0.0087000001221895
Sena Curve Load Maximum	1.0000
Sena Curve Load Minimum	0.0099999997764826
Sena Curve Square Loss	0.003800000064075
Sena Curve Test Cond Id	Curve fit of data measured in accordance with the US DOE Test Procedure for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 120V/60Hz electrical input and balanced resistive load (PF = 1.
Sena Curve X Axis Maximum	1.0000
Sena Curve X Axis Title	load
Sena Curve X Axis Units	percentage
Sena Curve Y Axis Maximum	1.0000
Sena Curve Y Axis Minimum	0.5000
Sena Curve Y Axis Title	efficiency
Sena Curve Y Axis Units	percentage
Sena Equipment Protection Policy	lifetime : $75000
Sena Graph Display	1.0000
Sena Heat Dissipation	16 Btu/h
Sena Input Voltage	120 V
Sena Input Voltage 1	120 V
Sena Input Voltage Limits	92…139 V
Sena Let Through Voltage Rating	5 V
Sena Maximum Configurable Power In Va	600 VA
Sena Maximum Configurable Power In W	330 W
Sena Mounting Mode	not rack-mountable
Sena Mounting Preference	no preference
Sena Nb Of Power Socket Outlets	2 NEMA 5-15R surge 5 NEMA 5-15R
Sena Network Frequency	50/60 Hz ± 3 Hz auto-sensing
Sena Noise Suppression	full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Sena Number Of Tare Power	3 W
Sena Operating Altitude	0…10000 ft
Sena Output Frequency	50/60 Hz ± 3 Hz sync to mains
Sena Output Voltage	120 V
Sena Output Voltage 1	120 V
Sena Plug Standard	NEMA 5-15P
Sena Product Certifications	California Energy Commission (CEC)# #cTUVus# #NOM
Sena Provided Equipment	user manual
Sena Provided Equipment 1	user manual
Sena Provided Equipment 2	user manual
Sena Rated Power In Va	600 VA
Sena Rated Power In W	330 W
Sena Redundant	No
Sena Relative Humidity	0-90 %
Sena Show Note Op Temperature	No
Sena Standards	FCC part 15 class B# #UL 1778
Sena Storage Altitude	0-50000 ft
Sena Storage Relative Humidity	0-95 %
Sena Surge Energy Rate	490 J
Sena Transfer Time	6 ms typical : 10 ms maximum
Sena Ups Size	WS
Sena Ups Type	standby
Sena Usb Compatible	No
Sena Wave Type	stepped approximation to a sinewave
