Schneider Electric EPP101-LCD

Name: Schneider Electric EPP101-LCD
Brand: Schneider Electric
SKU: CS3014782
Availability: OutOfStock

SKU: CS3014782MPN: EPP101-LCDAlternate Part #: SENA-EPP101-LCD

Differential Pressure Transducer, Dry Media, Panel Enclosure, Field Selectable Outputs, Range: 0-1”W.C./0-250Pa, TAC Label, LCD

Product Details

Differential Pressure Transducer

Dry Media* Panel Enclosure* Supply Voltage: 12-30 VDC/24 VAC* Field Selectable Outputs* Range: 0-1”W.C./0-250Pa* TAC Label* LCD Display

Us Rated Supply Voltage	12…30 V DC 24 V AC
Us Rated Supply Voltage 1	12…30 V DC 24 V AC
Ambient Air Temperature For Operation	5-60 °C
Ambient Air Temperature For Operation 1	5-60 °C
Ambient Air Temperature For Operation 2	5-60 °C
Analogue Output Type	4…20 mA# #0…5 V DC# #0…10 V DC
Burst Pressure	5 psid (34.5 kPa)
Controlled Fluid	dry
Device Application	panel installation
Function Available	push-button auto-zero and digital input (2-Position terminal block)
Measurement Temperature	0-50 °C
Mounting Support	panel
Pressure Measurement Drift	less than 2 %
Product Or Component Type	sensor
Proof Pressure	20.6 kPa
Targeted Region	North America.
Temperature Measurement Accuracy	± 1 % FS
Type Of Measurement	temperature
