Schneider Electric EHD110-100
SKU: CS3336505MPN: EHD110-100
RH and Temp Sensor: Duct, 2% Accuracy, Field Selectable Outputs, 1.8K Ohm Thermistor, Vista, TAC Label
$201.04
UnitAvailable on backorder
Product Details
Relative Humidity and Temperature Combo Sensor:
- Duct* 2% Accuracy* Field Selectable Outputs:
+ 4-20mA+ 0-5 VDC+ 0-10 VDC* 1.8K Ohm Thermistor* Vista* TAC Label
Attributes
| Product or Component Type | sensor |
| Location | plant room |
| Type of Measurement | humidity; temperature |
| Device Application | duct |
| Humidity Measurement Resolution | 0.1 % RH |
| Mounting Support | duct |
| Colour | cloud white |
| Sensor Type | temperature: 1.8 kOhm thermistor |
| Relative Humidity | 0-95 % RH, non-condensing (will recover from saturation) |
| Probe Length | 199 mm |
| (Us) Rated Supply Voltage | 15…36 V DC; 22…26 V AC |
| Humidity Measurement Drift | < 2 %, for 5 years |
Specifications
| SKU | CS3336505 |
|---|---|
| MPN | EHD110-100 |
