Veris H548
SKU: CS2541821MPN: H548Alternate Part #: VER-H548
Field Mount Motor Control Device: Combination Switching Relay, Current Status Switch, HOA Switch, 0.5-15 Amp, SPST Field Selectable, 24VAC/DC Coil, UL
$71.18
UnitAvailable on backorder
Product Details
Field Mount Motor Control Device:
- Combination Switching Relay, Current Status Switch* HOA Switch* 0.5-15 Amperage Range* Normally Open, 1.0A@30VAC-DC Status Output* 0.5A or less, Adjustable Trip Point* SPST Field Selectable Normally Open/Normally Closed Relay* 24VAC/DC Relay Coil* Status LEDs* Relay Power LED* UL Listed
Attributes
| Sena Ambient Air Temperature For Operation | -15-50 °C |
| Sena Ambient Air Temperature For Operation 1 | -15-50 °C |
| Sena Ambient Air Temperature For Operation 2 | -15-50 °C |
| Sena Awg Gauge | AWG 24…AWG 14 |
| Sena Awg Gauge 1 | AWG 24…AWG 14 |
| Sena Current Measurement Range | 0.25…15 A |
| Sena Device Application | building automation systems |
| Sena Load Type | motor:1 hpat120 V AC resistive: 15 Aat277 V AC |
| Sena Mounting Support | 4-gang junction box |
| Sena Network Frequency | 50…60 Hz |
| Sena Output Current | 1 A at 30 V AC/DC |
| Sena Output Current 1 | 1 A at 30 V AC/DC |
| Sena Output Current 2 | 1 A at 30 V AC/DC |
| Sena Product Certifications | UL |
| Sena Product Certifications 1 | UL |
| Sena Product Or Component Type | sensor |
| Sena Range Of Product | Motor Control Series |
| Sena Relative Humidity | 10-90 % RH, non-condensing |
| Sena Relative Humidity 1 | 10-90 % RH, non-condensing |
| Sena Relay Coil Voltage | 24-24 V AC 24-24 V DC |
| Sena Relay Type | mechanical |
| Sena Sensor Type | current transducer, AC, with relay |
| Sena Sensor Type 1 | current transducer, AC, with relay |
| Sena Switch Function | SPST |
| Sena Type Of Measurement | AC current |
Specifications
| SKU | CS2541821 |
|---|---|
| MPN | H548 |
| Alternate Part # | VER-H548 |
