Eaton XTCE050D00A

Name: Eaton XTCE050D00A
Brand: Eaton
SKU: CS2414827
Price: 255.76 USD
Availability: InStock

SKU: CS2414827MPN: XTCE050D00AAlternate Part #: MSAA277827UPC/EAN: 04015082778279

Eaton XT IEC contactor

Eaton XTCE040D00A, XTCE040D00E, XTCE040D00TD, XTCE050D00A, XTCE050D00B, XTCE050D00C, XTCE050D00E

Eaton XTCE040D00A, XTCE040D00E, XTCE040D00TD, XTCE050D00A

$255.76

Unit

5+ Units Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

Eaton XT IEC contactor, 50A, 110 Vac 50 Hz, 120 Vac 60 Hz, 0NO-0NC, 50A, Frame D, 55 mm, 50-60 Hz, 3, 7.5, 10/ 15, 20, 40, 50 hp (⅓PH @115, 200, 230/200, 230, 460, 575 V), Three-pole, Screw terminals, FVNR

Attributes

Amperage Rating	50A
Coil	110-120 Vac, 50/60 Hz
Coil Voltage	110-120 Vac, 50/60 Hz
Contact Configuration	0 NO, 0 NC
Continuous Ampere Rating	50 A
Frame Size	55 mm
Frequency Rating	50-60 Hz
Hp Rating Max	3, 7.5, 10/ 15, 20, 40, 50 hp (⅓PH @115,200,230/200,230,460,575 V)
Number Of Poles	Three-pole
Operation	Non-reversing
Series	XT IEC
Terminals	Screw terminals
Type	Full voltage non-reversing contactor
