Square D XCKJ10511H7

Name: Square D XCKJ10511H7
Brand: Square D
SKU: CS1656271
Price: 257.59 USD
Availability: InStock

SKU: CS1656271MPN: XCKJ10511H7

Limit switch, XC Standard, XCKJ, thermoplastic roller lever, 1NC+1 NO, snap action, ½NPT

$257.59

Unit

1 Unit Available at Factory - Ships Same/Next Business Day

Quantity

remove

add

Product Details

OsiSense Limit Switch

Body Type: Fixed* Head Type: Rotary head* Material: Metal* Movement of Operating Head: Rotary* Type of Operator: Spring return roller lever thermoplastic* Type of Approach: Lateral approach 1 or 2 programmable directions* Cable Entry: 1 entry tapped for ½ in. NPT cable gland* Number of Poles: 2 Poles* Contacts Type and Composition: 1 NC + 1 NO* Contact Operation: Snap Action* Electrical Connection: Screw-clamp terminals* Conventional Enclosed Thermal Current: 10A* Degree of Protection: IP66 conforming to IEC 60529

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-40-70 °C
Body Material	zamak
Body Type	fixed
Contact Operation	snap action
Contacts Insulation Form	Zb
Contacts Type And Composition	1 NC + 1 NO
Device Short Name	XCKJ
Fixing Mode	by the body
Head Material	zamak
Head Type	rotary head
Material	metal
Mechanical Durability	30000000 cycles
Minimum Torque For Tripping	0.25 N.m
Movement Of Operating Head	rotary
Number Of Poles	2.0
Positive Opening	with
Positive Opening Minimum Torque	0.5 N.m
Product Certifications	UL# #CSA# #CCC
Product Or Component Type	limit switch
Protective Treatment	TH
Range Of Product	Telemecanique Limit switches XC Standard
Series Name	standard format
Standards	EN 60947-5-1# #EN 60204-1# #CENELEC EN 50041# #IEC 60204-1# #CSA C22.2 No 14# #UL 508# #IEC 60947-5-1
Switch Actuation	by 30° cam
Terminals Description Iso N 1	(21-22)NC# #(13-14)NO
