Square D XBTN401

Name: Square D XBTN401
Brand: Square D
SKU: CS1647679
Availability: OutOfStock

SKU: CS1647679MPN: XBTN401

small panel with keypad - with matrix screen - G-O-R - 24 V

Discontinued - Contact Us For Pricing & Availability

Product Details

Small panel with keypad, With matrix screen, G-O-R, 24 V

Ambient Air Temperature For Operation	0-55 °C
Ambient Air Temperature For Operation 1	0-55 °C
Ambient Air Temperature For Storage	-20-60 °C
Character Font	ASCII# #Katakana# #Chinese (simplified Chinese)# #Greek# #Cyrillic
Cut Out Dimensions	119.4 (± 0.5) x 63 (± 0.4) mm
Display Colour	red# #green# #orange
Display Material	polyester
Display Resolution	122 x 32 pixels
Display Type	extra-bright matrix backlit LCD
Downloadable Protocols	Uni-TE# #Modbus# #third party protocols
Fixing Mode	by 2 spring clips
Front Material	PPT
Keypad Material	polyester
Local Signalling	6 LEDs
Marking	CE
Marking 1	CE
Memory Capacity	512 kB
Memory Type	flash
Messages Display Capacity	4 lines of 20 characters maximum# #1 line of 5 characters minimum
Number Of Customisable Keys	4.0000
Number Of Fixed Keys	4.0000
Number Of Key	8.0000
Number Of Pages	256 alarm pages# #200 application pages
Operating System	Magelis
Product Certifications	UL 1604# #ATEX zone 2/22# #CSA Class 1 Division 2# #UL Class 1 Division 2
Product Mounting	flush mounting
Product Or Component Type	small panel with keypad
Range Of Product	Magelis XBTN
Realtime Clock	access to the PLC real-time clock
Residual Ripple	1200 mV
Software Designation	Vijeo Designer Lite
Software Type	configuration software
Standards	IEC 60068-2-6# #IEC 61131-2# #CSA C22.2 No 14# #IEC 60068-2-27# #UL 508
Supply	external source
Supply Voltage Limits	18-30 V
