Square D ABL6TS25B

Name: Square D ABL6TS25B
Brand: Square D
SKU: CS4810553
Availability: OutOfStock

SKU: CS4810553MPN: ABL6TS25B

voltage transformer - 230..400 V - 1 x 24 V - 250 VA

Product Details

Voltage transformer - 230..400 V - 1 x 24 V - 250 VA

Ambient Air Temperature For Operation	-20-50 °C
Ambient Air Temperature For Operation 1	-20-50 °C
Ambient Air Temperature For Storage	-40-80 °C
Efficiency	0.89999997615814
Electrical Insulation Class	class B
Input Voltage Limits	360…440 V# #207…253 V
Input Voltage Tolerance	± 15 V
Ip Degree Of Protection	IP20
Marking	CE
Maximum Voltage Drop At Rated Load	0.0010000000474975
Network Frequency Limits	47-63 Hz
No Load Losses	12.5 W
Operating Altitude	3000 m
Power Dissipation In W	27.8 W
Product Certifications	UR# #EAC# #DNV-GL
Product Or Component Type	safety and isolation transformer
Protective Cover	without
Protective Treatment	TC
Range Of Product	Modicon Transformer Optimized
Rated Power In Va	250 VA
Secondary Winding	single
Short Circuit Voltage	0,0551
Standards	UL 506
