Telemecanique 9037HG30

Name: Telemecanique 9037HG30
Brand: Telemecanique
SKU: CS893293
Availability: OutOfStock

SKU: CS893293MPN: 9037HG30

Lqd Lvl Swch Hrzntl 2-½ MNPT ClsOnRse

Square D, Telemecanique 9037HG30, 9037HG30R, 9037HG30Z20, 9037HG31, 9037HG31R, 9037HG32, 9037HG32L, 9037HG33, 9037HG33F3Z20, 9037HG33R, 9037HG33Z20, 9037HG34, 9037HG34R, 9037HG35, 9037HG36

Product Details

Tank Liquid Level Switch Switch Function Close On Rise Side Mounting Float Position Left Float Rod Angle 90 Degrees Float Travel 6 ¼ in Tank Connection Size 2-½ in MNPT NEMA Rating 1 Contact Form DPST Operating Temp Range -22 Degrees to 220 Degrees F Max Pressure 50 psi Overall Length 16.06 in Float Material Stainless Steel Float Length 7.13 in Float Dia 2.58 in Stem Material Stainless Steel Stem Length 5.07 in Height 5.98 in Width 11.3 in Max Voltage 475 V

Attributes

Sena Ambient Air Temperature For Operation	-22-220 °F
Sena Ambient Air Temperature For Operation 1	-22-220 °F
Sena Ambient Air Temperature For Storage	-22-220 °F
Sena Device Application	closed tank
Sena Device Mounting	screw-in bushing
Sena Device Short Name	9037H
Sena Electrical Circuit Type	power circuit
Sena Enclosure Material	polypropylene or equivalent
Sena Factory Modification	without
Sena Float Position	left
Sena Float Rod Angle	90° (offset)
Sena Kit Composition	float# #rod# #float switch
Sena Local Signalling	with external pointer
Sena Materials In Contact With Fluid	nitrile (Buna-N) or equivalent rubber# #stainless steel 316# #stainlesss steel 304# #yellow brass# #cast iron
Sena Maximum Operating Rate	60 cyc/mn
Sena Mechanical Durability	300 cycles
Sena Operating Position	vertical position only
Sena Product Certifications	UL listed file E12158# #CSA file LR25490
Sena Product Destination	for closed tank
Sena Product Or Component Type	float switch
Sena Product Specific Application	liquid level control
Sena Quantity Per Set	set of 1
Sena Range Of Product	Square D Pumptrol
Sena Standards	CE# #UL 508
Sena Terminal Block Type	4 terminals
Sena Terminals Description Iso N 1	line-load-load-line
Sena Type Of Packing	individual
