Dwyer H2S-2

Name: Dwyer H2S-2
Brand: Dwyer
SKU: CS705457
Price: 2290.15 USD
Availability: OutOfStock

SKU: CS705457MPN: H2S-2Alternate Part #: 118008-00

H2S-2 25-250 \& 30-400 PSIG

$2,290.15

Unit

Available on backorder

Quantity

remove

add

Product Details

Duotect® dual-action explosion-proof pressure switch, 25-250 psig (1.72-17.2 bar) low range, 30-400 psig (2.07-27.6 bar) high range

Commodity Code	8100
Compliance	CSA, UL.
Conduit Connection	¾” female NPT.
Deadband	Approximately 10% of range.
Electrical Connection	18 AWG, 18” (460 mm) long.
Electrical Rating	5 A @ 125/250 VAC, 5 A res., 3 A ind. @ 30 VDC. Gold contacts optional.
Enclosure Rating	UL listed explosion-proof, Class I, Groups B, C, and D. Class II Groups E, F, and G. Meets NEMA 4X (IP66). CSA optional. Class I, Groups B, C & D. Class II, Groups E, F, & G -20°C x0089¤ Tamb x0089¤ 75°C T6 [optional -20°C x0089¤ Tamb x0089¤ 40°C T5] Type 4.
Mounting Orientation	Any position.
Pressure Limit	1500 psig (103 bar).
Process Connection	¼” female NPT.
Set Point Adjustment	Internal nut.
Switch Type	Two SPDT snap switches.
Wetted Material	316 SS chamber with FEP diaphragm and Buna-N O-ring standard. Fluoroelastomer or EPDM O-ring optional.
