Dwyer PMT2-05-A-U2

Name: Dwyer PMT2-05-A-U2
Brand: Dwyer
SKU: CS4119972
Price: 2685.96 USD
Availability: OutOfStock

SKU: CS4119972MPN: PMT2-05-A-U2Alternate Part #: 100673-55

PMT2-05-A-U2

$2,685.96

Unit

Available on backorder

Quantity

remove

add

Product Details

Particulate transmitter, 5” probe, UL intrinsically safe rating, ¾” male NPT process connections, ½” female NPT electrical connections

Attributes

Accuracy	±5% of reading.
Averaging Time	1 to 360 s (10 selectable options).
Commodity Code	0460
Compliance	CE, cULus; ATEX Compliant: 2813 II 1 G Ex ia IIB T4 GA (-40°C x0089¤ Tamb x0089¤ 63°C) (-40°C x0089¤ T Process x0089¤ 120°C) / II 1 D Ex ia IIIC T120°C Da (-40°C x0089¤ Tamb x0089¤ 63°C) (-40°C x0089¤ T Process x0089¤ 120°C). Type Certificate No.: DEMKO 16ATEX1768 X. ATEX Standards: EN 60079-0:2012/A11:2013; EN 60079-11:2012. IECEx Certified: Ex ia IIB T4 Ga (-40°C x0089¤ Tamb x0089¤ 63°C) (-40°C x0089¤ T Process x0089¤ 120°C) / Ex ia IIIC T120°C Da (-40°C x0089¤ Tamb x0089¤ 63°C) (-40°C x0089¤ T Process x0089¤ 120°C). Certificate of Conformity: IECEx UL 16.013X. IECEx Standards: IEC 60079-0: 2011; IEC 60079-11: 2011. UL Listed Intrinsically Safe for Class I, Groups C and D; Class II, Groups E, F and G; Class III; Class I Zone 0 AEx ia IIB T4 Ga; Class I Zone 0 Ex ia IIB T4 Ga.
Detection Range	5 to 5000 pA (6 selectable range options).
Electrical Connection	Two ½” female NPT conduit openings.
Enclosure	Powder coated aluminum.
Enclosure Rating	UL Type 4 (IP66), ATEX/IECEx IP65.
Mounting Orientation	Any.
Output Signal	4 to 20 mA.
Particulate Size	0.3 microns and higher.
Power Requirement	12 to 28 VDC.
Pressure Limit	30 psi (2 bar).
Process Connection	See model chart on catalog page.
Service	Air and compatible gases, any type of particulate conductive or nonconductive.
Terminal Block	Removable (16 to 20 AWG wire).
Wetted Material	316L SS, silicone, and PTFE.
