ACI A/SYPHON-180

Name: ACI A/SYPHON-180
Brand: ACI
SKU: CS6287817
Availability: OutOfStock

SKU: CS6287817MPN: A/SYPHON-180Alternate Part #: 137247

Syphon, ¼” MNPT, 180°, Schedule 40, 316 SS

Product Details

Syphon, ¼” MNPT, 180°, Schedule 40, 316 SS

Options	Syphon Bend: 180º

Thread Size	¼” Male NPT x ¼” Male NPT
Material Type	Welded 316 Series Stainless Steel
Pipe Schedule	Schedule 40 or Schedule 80; See ordering grid
Product Weight	A/SYPHON-90: 0.40 lbs (0.181 kg) \| A/SYPHON-90-H: 0.50 lbs (0.227 kg) A/SYPHON-180: 0.40 lbs (0.181 kg) \| A/SYPHON-180-H: 0.60 lbs (0.272 kg) A/SYPHON-270: 0.50 lbs (0.227 kg) \| A/SYPHON-270-H: 0.70 lbs (0.318 kg)
Agency Approvals	ASME Boiler and Pressure Vessel Code 1995, MIL-I Certified (Military equivalent of ISO 9000), RoHS2 Compliant, WEEE, Reach
Bend Configurations	90º, 180º, or 270º
