Siemens M3FB25LX/A
SKU: CS5318148MPN: M3FB25LX/AUPC/EAN: 7612914015846
0 to 10V, 1”Valve, Hot Gas Bypass, 9.3 Cv, 460 PSI
$3,597.53
UnitAvailable on backorder
Product Details
This M3FB Magnetic Valve is used for refrigeration applications. This 0 to 10V diverting valve is suitable for hot gas bypass and heat-recovery applications. This 1” valve has a 9.3 Cv, a maximum operating pressure of 460 psi and must be applied to closed loop applications.
Attributes
| Ambient Temperature Operation | -40…50 °C |
| Leakage Rate | 0.05 % of kvs |
| Material Inside Set | CrNi steel/brass |
| Material Valve Body | Steel |
| Medium Temperature | -40…120 °C; -40…248 ºF |
| Medium Temperature F Max | 248 ºF |
| Medium Temperature F Min | -40 ºF |
| Operating Voltage | 24 VAC |
| Permissible Operating Pressure | 4300 kPa |
| Positioning Time | 1 s |
| Power Consumption | 40 VA |
| Spring Return Function | AB- |
Specifications
| SKU | CS5318148 |
|---|---|
| MPN | M3FB25LX/A |
| UPC/EAN | 7612914015846 |
