Eaton 13156RD17B1

Name: Eaton 13156RD17B1
Brand: Eaton
SKU: CS5018896
Price: 161.44 USD
Availability: OutOfStock

SKU: CS5018896MPN: 13156RD17B1UPC/EAN: 782114458655

Eaton OEM Prism 18mm tubular photoelectric sensor

Product Details

Eaton OEM Prism 18mm tubular photoelectric sensor,Diffuse Reflective, 8 in range, Right, Output ON, 6.6 ft, 100 mA PNP, 250 mA NPN at 10-30 Vdc, PVC, NPN and PNP open collector, 10-30 Vdc

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Contact Configuration	NPN and PNP open collector
Contact Rating	100 mA PNP, 250 mA NPN at 10-30 Vdc
Enclosure Material	Polyurethane foam (RIM)
Environmental Rating	NEMA 1, NEMA 2, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, NEMA 16
Input Voltage	10-30 Vdc
Led Indicator	Output ON
Maximum Dc Current	100 mA PNP, 250 mA NPN
Operating Temperature Max	131 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-13 FAH
Operating Temperature Min Uom	FAH
Protection	Auto reset short circuit
Sensor Type	Diffuse reflective
Series	Comet
Type	Photoelectric Sensor
