Eaton 13107RSQD07

Name: Eaton 13107RSQD07
Brand: Eaton
SKU: CS5018860
Price: 408.07 USD
Availability: OutOfStock

SKU: CS5018860MPN: 13107RSQD07UPC/EAN: 782114403792

Eaton Comet 18mm tubular photoelectric sensor

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Right Angle, Sensor dist 6 In., 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open Collector, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 4 Pin M12 Connector, 10-30 Vdc input, Wide Beam Diffuse, 8 In.(.2m)

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Connection	4-pin M12 connector
Contact Configuration	NPN and PNP open collector
Contact Rating	100 mA PNP, 250 mA NPN at 10-30 Vdc
Enclosure Material	Lens: polycarbonate Body: structural polyurethane foam Cable jacket: PVC
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
Input Voltage	10-30 Vdc
Led Indicator	Output status: red
Maximum Dc Current	100 mA PNP, 250 mA NPN
Operating Mode	Wide beam diffuse
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Auto reset short circuit
Sensor Type	Wide angle diffuse
Switch Type	Photoelectric
