Eaton 13106AQD03

Name: Eaton 13106AQD03
Brand: Eaton
SKU: CS5018850
Price: 490.54 USD
Availability: OutOfStock

SKU: CS5018850MPN: 13106AQD03UPC/EAN: 782113843544

Eaton Comet 18mm tubular photoelectric sensor

$490.54

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 8 in, 300 mA max AC L1 switched/DC NPN open coll, 300 mA AC/DC at 20-264Vac/15-30Vdc, 4 Pin Dual Key Micro Connector, Diffuse Reflective, 8 in(.2m)

Attributes

Cable Type	Polyvinyl Chloride (PVC)
Connection	4-pin dual key micro connector
Contact Configuration	DC: NPN open collector AC: L1 switched
Contact Rating	300 mA AC/DC at 20-264Vac/15-30Vdc
Enclosure Material	Body: structural polyurethane foam Lens: polycarbonate Cable jacket: PVC
Environmental Rating	NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
Input Voltage	20-264 Vac, 15-30 Vdc
Led Indicator	Output status: red
Maximum Ac Current	300 mA
Maximum Dc Current	300 mA
Operating Mode	Diffuse reflective
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-40 FAH
Operating Temperature Min Uom	FAH
Protection	Latching short circuit
Sensor Type	Diffuse reflective
Switch Type	Photoelectric
