Square D ILM1001P32A0000

Name: Square D ILM1001P32A0000
Brand: Square D
SKU: CS4811515
Availability: OutOfStock

SKU: CS4811515MPN: ILM1001P32A0000

integrated servo motor- 2.5 Nm-3000 rpm-keyed shaft-multiturn-without brake-IP65

Product Details

Integrated servo motor- 2.5 Nm-3000 rpm-keyed shaft-multiturn-without brake-IP65

In Rated Current	1.4 A
In Rated Current 1	1.4 A
Us Rated Supply Voltage	250…700 V
Us Rated Supply Voltage 1	250…700 V
Centring Collar Diameter	95 mm
Circle Diameter Of The Mounting Holes	115 mm
Continuous Stall Current	1.8 A
Continuous Stall Torque	2.5 N.m
Device Short Name	ILM
Feedback Type	absolute multiturn SinCos Hiperface
Holding Brake	without
Maximum Axial Force Fa	0.2 x Fr
Maximum Current Irms	7.4 A
Motor Flange Size	100 mm
Mounting Holes Diameter	9 mm
Mounting Support	international standard flange
Nominal Output Power	600 W
Nominal Speed	3000 rpm
Nominal Torque	1.9 N.m
Number Of Motor Poles	8.0000
Number Of Motor Stacks	1
Number Of Mounting Holes	4.0000
Peak Stall Torque	9.6 N.m
Product Or Component Type	servo motor integrated drive
Range Of Product	PacDrive 3
Rotor Inertia	1.4 kg.cm²
Second Shaft	without second shaft end
Shaft Diameter	19 mm
Shaft End	keyed
Speed Feedback Resolution	128 periods
Type Of Cooling	natural convection

SKU	CS4811515
MPN	ILM1001P32A0000
