Square D HL100WS2M1

Name: Square D HL100WS2M1
Brand: Square D
SKU: CS4811412
Availability: OutOfStock

SKU: CS4811412MPN: HL100WS2M1UPC/EAN: 785901148951

Limit switch, L100/300, 9007,

Product Details

LIMIT SWITCH

Ithe Conventional Enclosed Thermal Current	20 A
Ambient Air Temperature For Operation	0-350 °F
Ambient Air Temperature For Operation 1	0-350 °F
Ambient Air Temperature For Storage	0-350 °F
Base Plate Style	style 2
Body Material	cast aluminium
Body Type	fixed
Ccw Operation Contacts	1 NC + 1 NO
Contact Form	Form Zb
Contact Operation	snap action
Contact Sequence Number	1.0000
Contacts Style	A
Contacts Usage	-
Cw Operation Contacts	1 NC + 1 NO
Device Short Name	L100# #L300
Fixing Mode	by the body
Function Available	-
Head Type	rotary head
Maximum Displacement Angle	80 °
Minimum Torque For Tripping	190 ozf.in
Number Of Poles	2.0
Positive Opening	without
Product Or Component Type	limit switch
Product Specific Application	mill switch
Protective Treatment	corrosion resistant gray paint
Range Of Product	L100/300
Repeat Accuracy	± 0.03 %
Sale Per Indivisible Quantity	1.0000
Series Name	severe duty mill
Switch Actuation	CW# #from left
Switch Function	DPDT-DB
Terminals Description Iso N 1	(3-4) right side contact# #(1-2) left side contact
Type Of Approach	lateral approach
