Square D L100WN2M16

Name: Square D L100WN2M16
Brand: Square D
SKU: CS1656726
Availability: OutOfStock

SKU: CS1656726MPN: L100WN2M16UPC/EAN: 785901161554

Limit switch, L100/300, 600 V 10amp type l +options

Product Details

LIMIT SWITCH 600V 10AMP

Ithe Conventional Enclosed Thermal Current	20 A
Ambient Air Temperature For Operation	-10-185 °F
Ambient Air Temperature For Operation 1	-10-185 °F
Ambient Air Temperature For Storage	-10-185 °F
Base Plate Style	style 2
Body Material	cast aluminium
Body Type	fixed
Ccw Operation Contacts	1 NC + 1 NO
Contact Form	Form XX
Contact Operation	slow-break, break before make
Contact Sequence Number	16.0000
Contacts Style	B
Contacts Type And Composition	2 NO
Contacts Usage	-
Cw Operation Contacts	1 NC + 1 NO
Device Short Name	L300# #L100
Fixing Mode	by the body
Function Available	neutral position
Head Type	rotary head
Maximum Displacement Angle	70 °
Minimum Torque For Tripping	95 ozf.in
Number Of Poles	2.0
Positive Opening	without
Product Or Component Type	limit switch
Product Specific Application	mill switch
Protective Treatment	corrosion resistant gray paint
Range Of Product	L100/300
Sale Per Indivisible Quantity	1.0000
Series Name	severe duty mill
Switch Actuation	from left or right# #CW and CCW
Switch Function	DPST-NO-DB
Terminals Description Iso N 1	(1-2) left side contact# #(3-4) right side contact
Type Of Approach	lateral approach
