Telemecanique 9013GHG2J99H

Name: Telemecanique 9013GHG2J99H
Brand: Telemecanique
SKU: CS4810245
Availability: OutOfStock

SKU: CS4810245MPN: 9013GHG2J99HUPC/EAN: 785901160175

Square D Pumptrol, pump or compressor switch 9013GH, adjustable diff., factory setting

Product Details

Power Pressure Switch

Range of Product: Square D Pumtrol* Pressure Sensor Size: 200 psi (40-170 psi)* Value of Setting: Specify pressure settings* Electrical Circuit Type: Power circuit* Pressure Sensor Type: Electromechanical Pressure Switch* Pressure Actuator: Diaphragm* Pressure Switch Type of Operation: Regulation between 2 thresholds* Scale Type: Adjustable differential* Local Display: Without* Contacts Type and Composition: NC-NO, Snap-action, DPST-DB, Form Zb* Cable Entry Number: 3 knock-outs for ½” conduit UL 508* Electrical Connection: Screw-clamp terminals* Degree of Protection: NEMA 1 conforming to UL 50, IP20 conforming to IEC 60529

Sena Adjustable Range On Rising Pressure	65-200 psi
Sena Ambient Air Temperature For Operation	-33-257 °F
Sena Ambient Air Temperature For Operation 1	-33-257 °F
Sena Ambient Air Temperature For Storage	-33-257 °F
Sena Approximate Adjustable Differential	20-40 psi
Sena Destruction Pressure	300 psi
Sena Electrical Circuit Type	power circuit
Sena Factory Modification	-
Sena Local Display	without
Sena Maximum Operating Rate	10 cyc/mn
Sena Mechanical Durability	300000 cycles
Sena Operating Position	any position
Sena Pressure Actuator	diaphragm
Sena Pressure Sensor Name	9013GH
Sena Pressure Sensor Type	electromechanical pressure switch
Sena Pressure Switch Type Of Operation	regulation between 2 thresholds
Sena Product Certifications	CSA file LR25490# #UL listed file E12158
Sena Product Specific Application	control electrically driven water pumps and air compressors
Sena Protective Treatment	none
Sena Quantity Per Set	1
Sena Range Of Product	Square D Pumptrol
Sena Scale Type	adjustable differential
Sena Setting	internal
Sena Standards	CE# #UL 508# #NSF ANSI 372
Sena Terminal Block Type	4 terminals
Sena Terminals Description Iso N 1	L2-T2# #L1-T1
Sena Type Of Packing	individual
Sena Value Of Setting	specify pressure settings
