Square D 2510MCR1

Name: Square D 2510MCR1
Brand: Square D
SKU: CS4809513
Availability: OutOfStock

SKU: CS4809513MPN: 2510MCR1UPC/EAN: 785901800613

Manual Starter - NEMA 7\&9 - 2P - Size M1 - 600VAC

Product Details

Integral Horsepower Manual Starter

Motor Power HP: 2 HP at 115V AC; 3 HP at 230V AC* Number of Phase: 1-Phase* System Voltage: 600V AC* Poles Description: 2-Pole* Control Type: Push-button* Local Signaling: No Indicator* Motor Starter Type: Non-Reversing* Electrical Connection: Pressure Wire Clamp

Auxiliary Contact Composition	without
Control Type	push-button
Control Type 1	push-button
Electrical Connection	pressure wire clamp
Motor Starter Type	non reversing
Motor Starter Type 1	non reversing
Nema Size	M-1
Number Of Thermal Units Required	1.0000
Poles Description	2P
Product Certifications	CSA LR26817 class 3218 04# #UL listed file E58760 CCN NPXZ
Product Or Component Type	Manual Starter
Range Of Product	M
Thermal Overload Type	melting alloy
