Schneider Electric M900ARW-VB

SKU: CS4806719MPN: M900ARW-VB

Spacelogic, Globe Valve Actuator, floating or proportional, spring return up, 24V AC/DC, 900 N, NEMA 4

Schneider Electric M900AE, M900AEW-S2, M900AR, M900ARW, M900ARW-S2, M900ARW-VB
$676.89
Unit
Available on backorder
remove
add

Documents

Product Details

Actuator: (M900ARW-VB):

  • Actuator Type: Electric
  • Control Signal: Floating, Proportional
  • Control Signal Range: 0 to 10 VDC, 2 to 10 VDC, 4 to 20mA with 500 ohm resistor
  • Loss of Power Type: Spring Return
  • Power Input Voltage: 20 to 29 VDC, 24 VAC, 24 VDC
  • Leads and Connections: Terminal Block
  • Force: 900 N
  • Mechanical Movement: Linear
  • Auxiliary Switch: Available as accessory
  • Protection Rating: IP65, NEMA 4
  • Product Line: Schneider Electric
  • Product Range: Spacelogic
  • Product Series: M900
  • Actuator Use: Globe Valves

Attributes

Us Rated Supply Voltage 20…29 V DC 24 V AC/DC
Actuator linear
Ambient Air Temperature For Operation -10-50 °C
Ambient Air Temperature For Storage -25-65 °C
Analogue Input Range 0…10 V DC 4…20 mA with 500 Ohm resistor
Control Type automatic reset
Force Lbf 202 lbf
Force N 900 N
Ip Degree Of Protection IP65
Motor Type brushless DC motor
Nema Degree Of Protection NEMA 4
Product Destination globe valve
Product Or Component Type actuator
Relative Humidity 15-95 % non-condensing
Switch Function 2 SPDT (optional)
Targeted Region North America.# #Europe
Taxoclass Id PTC_D54008_XXX

Specifications

SKUCS4806719
MPNM900ARW-VB
