Turck NI6U-EG08-AP6X-0.2-PSG3F
SKU: CS4209961MPN: NI6U-EG08-AP6X-0.2-PSG3FAlternate Part #: 4635899
4635899 - FERRITE, BARREL, DC, PIGTAIL M
$161.72
UnitAvailable on backorder
Product Details
Inductive Sensor
With Extended Switching Distance
- M8 × 1 threaded barrel
- Stainless steel, 1.4404
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Large switching distance
- High switching frequency
- Integrated protection against predamping
- Little metal-free spaces
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- Pigtail with male end M8 x 1
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M8 x 1 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M8 × 1 |
| Housing Material | Stainless steel, 1.4427 SO |
| Mounting | Non-flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP68 |
| Rated Switching Distance | 6 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 1.0 kHz |
Specifications
| SKU | CS4209961 |
|---|---|
| MPN | NI6U-EG08-AP6X-0.2-PSG3F |
| Alternate Part # | 4635899 |
