Turck BI1.5U-EG08-AP6X-0.2-PSG3M
SKU: CS3787912MPN: BI1.5U-EG08-AP6X-0.2-PSG3MAlternate Part #: 46005000
46005000 - FERRITE, BARREL, DC, PIGTAIL
$153.82
UnitAvailable on backorder
Product Details
Inductive Sensor
- Threaded barrel, M8 x 1
- Stainless steel, 1.4427 SO
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Extended temperature range
- High switching frequency
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- Pigtail with male end M8 x 1
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M8 x 1 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M8 × 1 |
| Housing Material | Stainless steel, 1.4427 SO |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP68 |
| Rated Switching Distance | 1.5 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 2.0 kHz |
Specifications
| SKU | CS3787912 |
|---|---|
| MPN | BI1.5U-EG08-AP6X-0.2-PSG3M |
| Alternate Part # | 46005000 |
