Dwyer UFM2-16

Name: Dwyer UFM2-16
Brand: Dwyer
SKU: CS4121689
Price: 4918.14 USD
Availability: OutOfStock

SKU: CS4121689MPN: UFM2-16Alternate Part #: 128103-01

UFM2-16 ULTSNIC FLWMTR 5-7”

$4,918.14

Unit

Available on backorder

Quantity

remove

add

Product Details

Compact ultrasonic flowmeter, pulse and 4-20 mA outputs, 5 to 7” (125 to 180 mm) pipe

Accuracy	±3% of flow reading for >0.98 ft/s (>0.3 m/s).
Agency Approval	CE.
Agency Approvals	CE.
Applicable Pipe Lining	None.
Applicable Pipe Material	Steel, copper, or plastic.
Commodity Code	R2GT
Display	Backlit: 3.27” H x 0.74” W (83.1 mm x 18.8 mm), 2 line x 16 characters.
Electrical Connection	16.4’ (5 m) cable.
Electrical Connections	16.4’ (5 m) cable.
Enclosure Material	Plastic polycarbonate.
Enclosure Rating	IP54.
Output	Analog: 1 opto-isolated: 4-20 mA; Error current: 3.5 mA; Load resistance: 620 Î© max; Pulse: 1 optoisolated MOSFET relay, 500 mA max, 166 pps max, 200 Hz max.
Pipe Outside Diameter	¾ to 7” (25 to 180 mm). Pipe size is dependent on pipe material and internal diameter.
Pipe Wall Thickness	0.02 to 0.39” (0.5 to 10 mm).
Power Consumption	7 W max.
Power Requirement	12-24 VDC/VAC.
Range	0.33 to 32.8 ft/s (0.1 to 10 m/s).
Repeatability	±0.15% of measured value.
Response Time	<1 s.
Service	Clean water with <3% by volume of particulate content.
