Dwyer PUB-20

Name: Dwyer PUB-20
Brand: Dwyer
SKU: CS4120096
Price: 11999.20 USD
Availability: OutOfStock

SKU: CS4120096MPN: PUB-20Alternate Part #: 124946-01

PUB-20 PORT FLRT MON W/ B XD

$11,999.20

Unit

Available on backorder

Quantity

remove

add

Product Details

Portable ultrasonic flowmeter converter Type B, 2” to 40” (50.7 to 1016 mm) pipe diameter range.

Attributes

Accuracy	±0.5 to 2% of flow reading for flow rate > 0.66 ft/s (0.2 m/s) and pipe ID > 2.95” (75 mm); ±3% of flow reading for flow rate > 0.66 ft/s (0.2 m/s) and pipe ID in range 0.512 to 2.95” (13 to 75 mm); ±6% of flow reading for flow rate < 0.66 ft/s (0.2 m/s).
Applicable Pipe Lining	Rubber, glass, concrete, epoxy, steel, other*.
Applicable Pipe Material	Carbon steel, SS, copper, UPVC/PVDF, concrete, galvanized steel, mild steel, glass, brass.
Commodity Code	R2GL
Compliance	CE.
Display	240 x 64 pixel graphic display, high contrast black on white with backlight; Languages: English, French, German, Swedish, Italian, Spanish, Portuguese, Russian, Norwegian, and Dutch; 5.2” W x 1.5” H.
Electrical Connection	Multi-pin Lemo plugs.
Electrical Connections	Multi-pin Lemo plugs.
Enclosure Rating	Converter: IP54; Transducers: IP51.
Input	Lemo connector cable from sensors.
Inputs	Lemo connector cable from sensors.
Materials	Flame retardant injection molded ABS plastic.
Output	Analog: 1 opto-isolated output: 4 to 20 mA, 0 to 16 mA or 0 to 20 mA (selectable); Error current: 0 to 26 mA (selectable); Load resistance: 620 Î© max; Pulse: 1 opto-isolated MOSFET relay, 150 mA max, 500 pps max, 200 Hz max.
Permissible Air Content	< 3% by volume.
Pipe Lining Thickness	< 1” (< 25 mm).
Pipe Wall Thickness	0.04 to 3” (1 to 75 mm).
Power Adapter	110/240 VAC adapter. UK, US, European adapters included.
Power Consumption	10.5 W.
Power Requirement	9 to 24 VDC, (1) 5-Cell NiMH battery, internal, factory replaceable (continuous operation time: 20 hours with back-light and output off) (recharging time: 6.5 hours, power adapter used).
Range	0.33 to 65.62 ft/s (0.1 to 20 m/s).
Repeatability	±0.5 % of measured value or ±0.066 ft/s (0.02 m/s).
Response Time	< 500 ms.
Service	Homogeneous liquids that do not contain air bubbles capable of ultrasonic wave propagation.
Turbidity	< 3% by volume of particulate content.
