Dwyer CX-41
SKU: CS4116745MPN: CX-41Alternate Part #: 124493-10
CX-41 PR SW 25-100 PSI ¼ (4)
$56.13
UnitAvailable on backorder
Product Details
Compressor pressure switch, 4 ports, range 25-100 psig (1.7-6.9 bar), approx. adj. deadband 20-30 psig (1.4-2.1 bar), max. pressure 129 psig (8.9 bar).
Attributes
| Agency Approval | CE. |
| Commodity Code | R2AA |
| Conduit Connection | ⅞” hole for ½” conduit hub (2 places). |
| Deadband | See Ordering page. |
| Electrical Connection | Screw terminal. |
| Electrical Connections | Screw terminal. |
| Electrical Rating | 20 A @ 120 VAC, 12 A @ 240 VAC, 9.6 A @ 240 VAC (3 phase), 8.6 A @ 32 VDC, 3.1 A @ 120 VDC, 1.6 A @ 240 VDC. 1.5 HP @ 120 VAC, 2 HP @ 240 VAC, 3 HP @ 240 VAC (3 phase), 0.25 HP @ 32/120/240 VDC. |
| Electrical Ratings | 20 A @ 120 VAC, 12 A @ 240 VAC, 9.6 A @ 240 VAC (3 phase), 8.6 A @ 32 VDC, 3.1 A @ 120 VDC, 1.6 A @ 240 VDC. 1.5 HP @ 120 VAC, 2 HP @ 240 VAC, 3 HP @ 240 VAC (3 phase), 0.25 HP @ 32/120/240 VDC. |
| Enclosure Rating | General purpose. |
| Mounting Orientation | Switch can be installed in any position. |
| Pressure Limit | See Ordering page. |
| Process Connection | ¼” female NPT (CX-4: 4 places). |
| Repeatability | ±5 psig (±0.3 bar). |
| Service | Air and non-combustible compatible gases. |
| Setpoint Adjustment | Internal screws. |
| Switch Type | 2 each SPST snap action, normally closed (NC). |
| Wetted Material | NBR (Nitrile-Butadiene) rubber diaphragm, steel connection (CX-1), aluminum alloy connection (CX-4). |
Specifications
| SKU | CS4116745 |
|---|---|
| MPN | CX-41 |
| Alternate Part # | 124493-10 |
