All ProductsTurck

Turck RI-01T4F1-2A50-C

SKU: CS3832252MPN: RI-01T4F1-2A50-CAlternate Part #: 1546687

1546687 - INCREMENTAL

Turck RI-01QA0F1-2D40-C, RI-01T4F1-2A100-C, RI-01T4F1-2A200-C, RI-01T4F1-2A50-C, RI-01T4F1-2D360-C
$462.79
Unit
Available on backorder
remove
add

Product Details

Incremental Shaft Encoder

Industrial Line

  • Synchro flange, Ø 24 mm
  • Solid shaft, Ø 4mm × 10 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP50 on shaft side
  • ‐20…+85 °C
  • Max. 12000 rpm
  • 8…30 VDC
  • Cable connection, 8-pin
  • Push-pull with inversion
  • Pulse frequency max. 160 kHz
  • 50 pulses per revolution

Attributes

Ambient Temperature -20…+85 °C
Ecl Ss Code V5 1 4 27270502 -/- Encoder, incremental
Electrical Connection Cable
Encoder Line Industrial-Line
Flange Diameter Ø  24 mm
Flange Type Synchro flange
Housing Material Aluminium
Operating Voltage 8…30 VDC
Output Function Push-Pull/HTL, with inverted signals
Output Type Incremental
Protection Class Housing IP64
Protection Class Shaft IP50
Resolution Incremental 50  ppr
Shaft Diameter D Mm 4 mm
Shaft Type Solid shaft
Technology Optical

Specifications

SKUCS3832252
MPNRI-01T4F1-2A50-C
Alternate Part #1546687
