Turck REI-E-111TA0C-2B360-C

SKU: CS3832111MPN: REI-E-111TA0C-2B360-CAlternate Part #: 100011964UPC/EAN: 4047101545869

100011964 - INCREMENTAL

Turck REI-E-111TA0C-2B1024-C, REI-E-111TA0C-2B360-C
Contact us for pricing and availability

Product Details

Incremental Encoder

Efficiency Line

  • Ø 42 mm clamping flange
  • Solid shaft, Ø 6mm x 12.5mm
  • Optical measuring principle
  • Shaft material, stainless steel
  • Protection class IP64 on housing and shaft side
  • ‐20…+70 °C
  • Max. 4500 rpm
  • 10…30 VDC
  • Cable connection, 8-pole
  • Push-pull, with inverted signals
  • Pulse frequency max. 300 kHz
  • 360 pulses per revolution

Attributes

Ambient Temperature -20…+70 °C
Customs Tariff Number 90318080000.0000
Ecl Ss Code V5 1 4 27270502 -/- Encoder, incremental
Electrical Connection Cable
Encoder Line Efficiency-Line
Flange Diameter Ø  40 mm
Flange Type Synchro/clamping flange
Housing Material Aluminium
Operating Voltage 10…30 VDC
Output Function Push-Pull/HTL, with inverted signals
Output Type Incremental
Protection Class IP64
Protection Class Shaft IP64
Resolution Incremental 360  ppr
Shaft Diameter D Mm 6.35 mm
Shaft Type Solid shaft
Technology Optical

Specifications

SKUCS3832111
MPNREI-E-111TA0C-2B360-C
Alternate Part #100011964
UPC/EAN4047101545869
