Turck NI2-Q9.5-ADZ32-0.1-FSB5.4X4/S304
SKU: CS3813995MPN: NI2-Q9.5-ADZ32-0.1-FSB5.4X4/S304Alternate Part #: 4200210
4200210 - FERRITE, CLAMP, AC, CON. M12
Contact us for pricing and availability
Product Details
Inductive Sensor
Monitoring Kit for Power Clamps
- Rectangular, height 23.5 mm
- Plastic, PP GR-20
- Resistant to magnetic fields (weld-resistant), for DC and AC fields up to 100 mT
- AC 4-wire, 20…250 VDC
- DC 4-wire, 10…300 VDC
- 2 x NO contact
- ½” male connector
Attributes
| Ambient Temperature | -25…+70 °C |
| Customs Tariff Number | 85365080900.0000 |
| Design | Monitoring kit for power clamps |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, ½″ |
| Housing Material | Metal, PBT-GF20-V0 |
| Mounting | Non-flush |
| Operating Voltage | 20…250 VAC / 10…300 VDC |
| Output Function | 2 x NO contact, 2-wire |
| Protection Class | IP67 |
| Rated Switching Distance | 2 mm |
| Special Feature | Resistant to magnetic fields |
| Switching Frequency | 0.020 kHz |
Specifications
| SKU | CS3813995 |
|---|---|
| MPN | NI2-Q9.5-ADZ32-0.1-FSB5.4X4/S304 |
| Alternate Part # | 4200210 |
