Turck BI1.5-EG08F-AP6X-0.2-PSG3M
SKU: CS3787798MPN: BI1.5-EG08F-AP6X-0.2-PSG3MAlternate Part #: 4614679
4614679 - FERRITE, BARREL, DC, PIGTAIL M
Contact us for pricing and availability
Product Details
Inductive Sensor
Stainless Steel Front
- Threaded barrel, M8 x 1
- Stainless steel, 1.4305
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- Pigtail with male end M8 x 1
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M8 x 1 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M8 × 1 |
| Housing Material | Stainless steel, 1.4305 (AISI 303) |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP67 |
| Rated Switching Distance | 1.5 mm |
| Special Feature | All-metal sensor, Pressure resistant |
| Switching Frequency | 0.20 kHz |
Specifications
| SKU | CS3787798 |
|---|---|
| MPN | BI1.5-EG08F-AP6X-0.2-PSG3M |
| Alternate Part # | 4614679 |
