Turck NI3-EG08K-AP6X-0.2-PSG3M

SKU: CS3652904MPN: NI3-EG08K-AP6X-0.2-PSG3MAlternate Part #: 4669610UPC/EAN: 4047101266139

4669610 - FERRITE, BARREL, DC, PIGTAIL M

Turck NI3-EG08K-AP6X-0.2-PSG3M
$154.01
Unit
Available on backorder
remove
add

Product Details

Inductive Sensor

  • Threaded barrel, M8 × 1
  • Stainless steel, 1.4305 (AISI 303)
  • DC 3-wire, 10…30 VDC
  • NO contact, PNP output
  • Pigtail with male end M8 x 1

Attributes

Ambient Temperature -25…+70 °C
Construction Size M8 x 1
Customs Tariff Number 85365019900.0000
Design Threaded barrel
Ecl Ss Code V5 1 4 27270101 -/- Inductive proximity switch
Electrical Connection Cable with connector, M8 × 1
Housing Material Stainless steel, 1.4305 (AISI 303)
Mounting Non-flush
Operating Voltage 10…30 VDC
Output Function NO contact, PNP
Protection Class IP67
Rated Switching Distance 3 mm
Switching Frequency 3.0 kHz

Specifications

SKUCS3652904
MPNNI3-EG08K-AP6X-0.2-PSG3M
Alternate Part #4669610
UPC/EAN4047101266139
