Eaton E50SN

SKU: CS3661961MPN: E50SNUPC/EAN: 782113308807

Eaton E50 NEMA heavy duty plug-in limit switch

Eaton E50AH1RFY1, E50AL16P20, E50AL1P5, E50ALH1, E50ALH16P, E50ALL1, E50ALL16P, E50ALM1, E50ALM16P, E50ALM16P20, E50ALR1, E50ALR16P, E50ALR16P12, E50ALR16P20, E50ALR16PC
Eaton E50SN, E50ST
Eaton E50SN, E50ST
Eaton E50SN, E50ST
Eaton E50SN, E50ST
Eaton E50AH1RFY1, E50AL16P20, E50AL1P5, E50ALH1, E50ALH16P, E50ALL1, E50ALL16P, E50ALM1, E50ALM16P, E50ALM16P20, E50ALR1, E50ALR16P, E50ALR16P12, E50ALR16P20, E50ALR16PC
Eaton E50SN, E50ST
$262.58
Unit
Available on backorder
remove
add

Product Details

Eaton E50 NEMA heavy duty plug-in limit switch, Switch body only, E50, 10A at 240 Vac, 1A at 250 Vdc, 1NO-1NC, Die cast zinc, NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13, IP67, 10A continuous, 1A, 14° to 201°F (-10° to 94°C), E50

Attributes

Contact Configuration 1 NO-1 NC
Contact Rating 10A at 240 Vac, 1A at 250 Vdc
Enclosure Material Die cast zinc
Environmental Rating NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
Maximum Ac Current 10 A continuous
Maximum Dc Current 1 A
Operating Temperature Max 201 FAH
Operating Temperature Max Uom FAH
Operating Temperature Min 14 FAH
Operating Temperature Min Uom FAH
Series E50
Special Features Switch body only
Type E50

Specifications

SKUCS3661961
MPNE50SN
UPC/EAN782113308807
