Square D 9007MS01S0500

Name: Square D 9007MS01S0500
Brand: Square D
SKU: CS353956
Availability: OutOfStock

SKU: CS353956MPN: 9007MS01S0500UPC/EAN: 785901550556

Limit switch, 9007, 240 VAC 10amp ms +options

Product Details

LIMIT SWITCH 240VAC 10AMP MS +OPTION

Ithe Conventional Enclosed Thermal Current	0.417
Ambient Air Temperature For Operation	-40-220 °F
Ambient Air Temperature For Operation 1	-40-220 °F
Ambient Air Temperature For Storage	-40-220 °F
Body Material	cast zinc
Body Type	fixed
Contact Form	Form C
Contact Operation	snap action
Contacts Material	silver contacts
Contacts Type And Composition	NC-NO
Device Short Name	9007MS/ML
Electrical Durability	100000 cycles
Fixing Mode	by the body
Head Type	plunger head
Marking	UL# #CSA# #CE
Material	metal
Maximum Force For Tripping	80 ozf
Mechanical Durability	10000000 cycles
Movement Of Operating Head	linear
Number Of Poles	1
Positive Opening	without
Product Certifications	CSA# #UL# #CE
Product Or Component Type	limit switch
Protective Treatment	epoxy powder coat
Range Of Product	9007
Sale Per Indivisible Quantity	1.0000
Sensor Design	miniature
Series Name	miniature potted
Standards	E78403# #LR 25490 Class 32 11 03
Switch Actuation	on end
Switch Function	SPDT
Terminals Description Iso N 1	(black)com# #(red)NC# #(white)NO# #(green-yellow)gnd
Wire Insulation Material	PVC
