Square D XUVU06M3KSNM8

Name: Square D XUVU06M3KSNM8
Brand: Square D
SKU: CS3360929
Availability: OutOfStock

SKU: CS3360929MPN: XUVU06M3KSNM8

Photoelectric sensors XU, ultrasonic sensor label fork 60x3, 12...24 V DC, PNP/NPN NO/NC connect M8

Product Details

Ultrasonic sensor label fork 60x3 - 12..24 V DC - PNP/NPN NO/NC connect M8

Ambient Air Temperature For Operation	5-55 °C
Ambient Air Temperature For Operation 1	5-55 °C
Ambient Air Temperature For Storage	-20-70 °C
Detection System	thru beam
Discrete Output Function	2 NO/NC programmable
Discrete Output Type	PNP and NPN
Electronic Sensor Type	photo-electric sensor
Enclosure Material	zinc alloy
Lens Material	PC
Material	metal
Maximum Delay First Up	30 ms
Maximum Delay Recovery	0.3 ms
Maximum Delay Response	0.3 ms
Maximum Passing Speed Of Object	180 m/min
Minimum Distance Between Labels	2 mm
Output Type	solid state
Product Certifications	cULus# #CE
Product Specific Application	detection of transparent labels
Range Of Product	Telemecanique Photoelectric sensors XU
Sensor Design	fork
Sensor Name	XUV
Series Name	Application packaging
Setting Up	numeric potentiometer
Supply Circuit Type	DC
Switching Frequency	<= 1500 Hz
Type Of Output Signal	discrete
Type Of Setting	without
Wiring Technique	4-wire
