Square D XUVF250M12

Name: Square D XUVF250M12
Brand: Square D
SKU: CS1670293
Availability: OutOfStock

SKU: CS1670293MPN: XUVF250M12

Photoelectric sensors XU, XUV, frame, 200X250mm, 12...24 VDC, M12

Product Details

Photo-electric sensor-XUV, Frame, 200X250mm, 12..24VDC, M12

Ambient Air Temperature For Operation	0-60 °C
Ambient Air Temperature For Operation 1	0-60 °C
Ambient Air Temperature For Storage	-20-80 °C
Detection System	thru beam
Discrete Output Function	1 NO or 1 NC programmable
Discrete Output Type	PNP or NPN
Electronic Sensor Type	photo-electric sensor
Enclosure Material	painted aluminium
Lens Material	altuglass
Material	metal
Maximum Delay First Up	100 ms
Output Type	solid state
Product Certifications	CE# #cULus
Product Specific Application	dynamic detection of passage of objects# #static detection of passage of objects
Range Of Product	Telemecanique Photoelectric sensors XU
Sensor Design	frame
Sensor Name	XUV
Series Name	Application material handling
Setting Up	sensitivity adjustment with potentiometer
Supply Circuit Type	DC
Switching Frequency	> 5000 Hz
Type Of Output Signal	discrete
Way Dimensions Of Optical Frame	200 x 250 mm
Wiring Technique	4-wire
