Dwyer 477B-1
SKU: CS3342161MPN: 477B-1Alternate Part #: 100485-50
477B-1 DGTL MANO 0-20 IN
$582.44
UnitAvailable on backorder
Product Details
Handheld digital manometer, 0 to 20” w.c. (0 to 4.982 kPa)
Attributes
| Accuracy | ±0.10% of full scale from 60 to 78F° (15.6 to 25.6°C); ±1% of full scale from 32 to 60 and 78 to 104°F (0 to 15 .6 and 25.6 to 40°C). |
| Agency Approval | CE. |
| Commodity Code | 0239 |
| Connection | Two barbed connections for use with ⅛” (3.18 mm) or 3/16” (4.76 mm) I.D. tubing for 477B-1, 477B-2, 477B-3, 477B-4 and 477B-5 only. Two compression fittings for use with ⅛” (3.18 mm) I.D. x ¼” (6.35 mm) O.D. tubing for 477B-6 and 477B-7 only. |
| Display | 4-digit LCD (.425” H x .234” W digits). |
| Power Requirement | 9 V alkaline battery. Battery included but not connected. |
| Pressure Hysteresis | ±0.1% of full scale. |
| Pressure Limit | See chart on catalog page. |
| Resolution | See chart on catalog page. |
| Service | Air and compatible gases. |
| Storage Temperature Limits | -4 to 176°F (-20 to 80°C). |
| Wetted Parts | Consult factory. |
Specifications
| SKU | CS3342161 |
|---|---|
| MPN | 477B-1 |
| Alternate Part # | 100485-50 |
