Square D LC2K1201B72

Name: Square D LC2K1201B72
Brand: Square D
SKU: CS3157648
Availability: OutOfStock

SKU: CS3157648MPN: LC2K1201B72

TeSys K reversing contactor , 3P , AC-3 \<\= 440 V 12 A , 1 NC , 24 V AC coil

Product Details

TeSys K reversing contactor, 3P, AC-3 \<\= 440 V 12 A, 1 NC, 24 V AC coil

Ambient Air Temperature For Operation	-25-50 °C
Ambient Air Temperature For Operation 1	-25-50 °C
Ambient Air Temperature For Storage	-50-80 °C
Auxiliary Contact Composition	1 NC
Coil Technology	built-in bidirectional peak limiting diode suppressor
Contactor Application	motor control# #resistive load
Device Application	control
Device Presentation	preassembled with reversing power busbar
Device Short Name	LC2K
Interlocking Type	mechanical
Mechanical Durability	5 Mcycles
Mounting Support	rail# #plate
Overvoltage Category	III
Pole Contact Composition	3 NO
Poles Description	3P
Product Certifications	UL# #CSA# #UKCA
Product Name	TeSys K
Product Or Component Type	reversing contactor
Range	TeSys
Signalling Circuit Frequency	<= 400 Hz
Standards	NF C 63-110# #VDE 0660# #IEC 60947# #BS 5424
Utilisation Category	AC-1# #AC-4# #AC-3
