Veris PHX07S
Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa
Product Details
The PH Series pressure transducers are designed for steam, air, gas, and liquid pressure measurement in all media compatible with 17-4 PH stainless steel. They utilize a microprocessor controlled sensor profiled for exceptional accuracy and reliability. All models feature three switch-selectable ranges and a “test mode” to verify wiring and panel input scaling. A pushbutton and digital input terminal is used to automatically zero the output, and the microprocessor safeguards against accidental zero adjustment during operation. The field-selectable output, offering options of 0-5V, 0-10VDC, or 4-20mA, ensures excellent systems compatibility. Jumper controlled surge damping is provided on all models to prevent false alarms.
Digitally Controlled Gauge
- Pressure Transducer* 0-100 psig* Standard
Attributes
| Analogue Output Type | 4…20 mA; 0…5 V DC; 0…10 V DC |
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -10-55 °C |
| Burst Pressure | 500 psig (34 bar) |
| Controlled Fluid | water |
| Fitting Size | ¼” NPT |
| Fitting Type | male |
| Location | plant room |
| Pressure Measurement Accuracy | ± 1 % FS |
| Pressure Measurement Range | 0…100 psi (0…7 bar) |
| Wiring Technique | 3-wire |
| Type of Measurement | gauge pressure |
| Device Application | pump and compressor monitoring; gas pressure; energy and water management; refrigerant equipment monitoring |
| Mounting Support | panel |
| Relative Humidity | 0-90 % RH, non-condensing |
| (Us) Rated Supply Voltage | 24 V AC |
| Local Signalling | red/green LED |
Specifications
| SKU | CS2543339 |
|---|---|
| MPN | PHX07S |
| Alternate Part # | VER-PHX07S |
