Veris H606
SKU: CS2541825MPN: H606Alternate Part #: VER-H606
Current Switch: Adjustable Trip Point, 1.25-50 Amp Range, Normally Closed 0.1A@30VDC, 1.25A or less Minimum Trip Point, Split-Core Housing
$73.06
UnitAvailable on backorder
Product Details
Current Switch:
- Adjustable Trip Point* 1.25-50 Amperage Range* Normally Closed 0.1A@30VDC* 1.25A or less Minimum Trip Point* Split-Core Housing* Sensor Power 5-30VDC* Insulation Class 600VAC rms (UL), 300VAC RMS (CE)* Frequency Range 50/60 Hz* Temperature Range -15 deg. to 60 deg. C (5 deg. to 140 deg. F)* Humidity Range 10-90% RH, non-condensing* Hysteresis 10% (typical)* Off State Leakage 34A@5VDC, 200A@30VDC* On State Voltage Drop 1.9VDC max@0.1A* Terminal Block Maximum Wire Size 14 AWG* Terminal Block Torque (nominal) 4 in-lbs (0.45 N-m)* Agency Approvals UL 508 open device listing CE: EN61010-1:2001-02, CAT III, deg. 2, basic insulation
Attributes
| Product or Component Type | sensor |
| Ambient Air Temperature for Operation | -15-60 °C |
| Product Certifications | UL; CE |
| Type of Measurement | AC current |
| Device Application | building automation systems |
| Mounting Support | split core housing |
| Sensor Type | current switch, AC |
| Relative Humidity | 10-90 % RH, non-condensing |
| Network Frequency | 50…60 Hz |
| AWG Gauge | AWG 24…AWG 14 |
| Output Current | 0.1 A at 30 V DC |
| Current Measurement Range | 1.25…50 A |
| Opening Width | 12 mm |
Specifications
| SKU | CS2541825 |
|---|---|
| MPN | H606 |
| Alternate Part # | VER-H606 |
