Turck FCS-GL1/2A4-AP8X-H1141
SKU: CS2423858MPN: FCS-GL1/2A4-AP8X-H1141Alternate Part #: 6870204UPC/EAN: 4047101172416
6870204 - CAL (IMM), COMP-MON, GEN., GEN
$856.36
UnitAvailable on backorder
Product Details
Flow Monitoring
Immersion Sensor with Integrated Processor
- Sensor for liquid media
- Calorimetric principle
- Adjustment via potentiometer
- Status indicated via LED chain
- DC 3-wire, 19.2…28.8 VDC
- NO contact, PNP output
- Connector device, M12 × 1
Attributes
| Ambient Temperature | -20…+80 °C |
| Approvals | UL |
| Customs Tariff Number | 90261021000.0000 |
| Design | Immersion |
| Detection Type | Calorimetric |
| Ecl Ss Code V5 1 4 | 27273190 -/- Flow meter (not classified) |
| Electrical Connection | Connector, M12 × 1 |
| Function | Flow monitoring |
| Housing Material | Stainless steel, 1.4571 (AISI 316Ti) |
| Medium | liquids |
| Medium Temperature | -20…+80 °C |
| Operating Voltage | 19.2…28.8 VDC |
| Output Function | NO contact, PNP |
| Process Connection | G ½” long version |
| Protection Class | IP67 |
| Sensor Material | Stainless steel |
Specifications
| SKU | CS2423858 |
|---|---|
| MPN | FCS-GL1/2A4-AP8X-H1141 |
| Alternate Part # | 6870204 |
| UPC/EAN | 4047101172416 |
