Honeywell CTS-20-250-VFD-001

SOLID CORE LOOP POWERED, TRUE RMS, CURRENT SENSOR W/ 4-20MA OUTPUT, 0-100/0-200/0-250 AMPS

Depending on the model, current is converted into a linear and proportional output signal of 0-5 Vdc, 0-10 Vdc or 4-20 mA and monitored by a building management controller. These Fast acting current sensors are reliable and extremely easy to install.

Product Features

• Fast response time
• Integral DIN rail mounting flange
• Easy wiring, polarity sensitive output
• Accepts up to a 350 MCM (17.3 mm) cable
• Operates up to 250 continuous amps
• True RMS versions are available
• RoHS and WEEE Complaint
• Limited 5 Year Warranty

Product Specifications

• 12-30 Vdc Supply Power,
• 5-104 Degree Operating Temperature Range,
• ± 0.5 % Accuracy,
• 36 mA Max Supply Current,
• 4-20 mA Average True RMS Output Switch Rating,
• 2200 Vac Isolation Voltage,
• Current Ratings: 0-200 Amps, 0-250 Amps, 0-100 Amps,
• 1 ⅜” DIN Rail Size
