Square D RE88867105

Name: Square D RE88867105
Brand: Square D
SKU: CS1686309
Availability: OutOfStock

SKU: CS1686309MPN: RE88867105

Universal timing relay, Zelio Time, plug in, 0.1 s..60 mn, 24...240 V AC, 1 OC

Product Details

Zelio Universal Timing Relay

Time Delay Range: 0.1s - 60mn* Rated Supply Voltage: 24-240V AC 50/60 Hz, 24V DC* Contacts Type and Composition: 1 OC* Rated Current: 8A AC* Degree of Protection: IP20 (terminal block) conforming to IEC 60529

In Rated Current	0.333
In Rated Current 1	0.333
Ambient Air Temperature For Operation	-20-60 °C
Ambient Air Temperature For Operation 1	-20-60 °C
Ambient Air Temperature For Storage	-30-60 °C
Breaking Capacity	2000 VA
Breaking Capacity 1	2000 VA
Component Name	RE88867
Contacts Material	AgNi (cadmium free)
Discrete Output Type	relay
Housing Material	self-extinguishing
Immunity To Microbreaks	10 ms
Marking	CE
Marking 1	CE
Maximum Switching Current	0.333
Maximum Switching Voltage	250 V
Mechanical Durability	5000000 cycles
Minimum Switching Current	10 mA
On Load Factor	1.0000
Product Certifications	CSA# #cURus# #GL
Product Or Component Type	Universal timing relay
Range Of Product	Zelio Time
Standards	IEC 60669-2-3# #93/68/EEC# #EN 50081-½# #IEC 61812-1# #EN 50082-½# #73/23/EEC# #89/336/EEC
Temperature Drift	± 0.05 %/°C
Time Delay Range	6…60 s# #1…10 h# #1…10 min# #6…60 min# #1…10 s# #10…100 h# #0.1…1 s
Time Delay Type	At# #B# #Ht# #Ac# #H# #D# #W# #Di# #A# #C
Time Delay Type 1	At# #B# #Ht# #Ac# #H# #D# #W# #Di# #A# #C
Voltage Drift	± 0.2 %/V
Voltage Range	0.85…1.1 Us
