Square D XPSDME1132P

Name: Square D XPSDME1132P
Brand: Square D
SKU: CS1679524
Availability: OutOfStock

SKU: CS1679524MPN: XPSDME1132P

module XPSDM - 6 coded magnetic switch - 24 V DC

Product Details

Module XPSDM - 6 Coded Magnetic Switch - 24 V DC

Ambient Air Temperature For Operation	-10-55 °C
Ambient Air Temperature For Operation 1	-10-55 °C
Ambient Air Temperature For Storage	-25-85 °C
Function Of Module	coded magnetic switch monitoring
Input Protection Type	internal, electronic
Maximum Line Resistance	100 Ohm
Maximum Response Time On Input Open	20 ms
Mounting Support	35 mm symmetrical DIN rail
Number Of Additional Circuits	2 solid state outputs
Product Certifications	TÜV# #UL# #CSA
Product Or Component Type	Preventa safety module
Range Of Product	Preventa Safety automation
Safety Module Application	monitoring 6 coded magnetic switches
Safety Module Name	XPSDME
Standards	EN/IEC 60947-5-1# #EN 1088/ISO 14119# #EN/IEC 60204-1
Synchronisation Time Between Inputs	< 0.5 s
